TF.35 Milling Drilling Machine • 35mm Capacity • Electromagnetic Clutch

The ERLO TF.35 is a heavy-duty milling drilling machine designed for drilling, tapping and light milling operations in production and toolroom environments. Built around a rigid prismatic column with a fixed base and sliding head design, the TF.35 combines the versatility of a milling machine with the productivity of an industrial drilling machine. The machine is equipped with a large cross table and motorised head movement, providing excellent positioning control for larger workpieces and more demanding machining tasks.

With a drilling capacity of 35mm, tapping capacity of M35 and milling capacity of 55 cm³/min, the TF.35 is suited to a wide range of fabrication, maintenance and precision engineering applications. The geared head transmission provides 16 spindle speeds, while the automatic feed system with electromagnetic clutch delivers consistent drilling performance and improved operator productivity. Standard equipment includes coolant, lighting, sensitive feed control and a comprehensive low-voltage electrical control system.
