PPCD-100 • 100 Ton • Upper Piston • Lower Table • Stroke Control Switch • Hand Buttons

Product Code: 10103-PPCD-100

This 100-ton C-frame press is suitable for performing work involving deep-drawing, forming, stamping, and riveting.

This press is equipped with a bolster table that has a working height of 900 mm and T-grooves.  The piston stroke is adjusted with end-stroke switches and comes with two speeds and a pressure switch.  The standard piston stroke is 250 mm.

All our C-frame presses are made in Europe and delivered according to the latest CE standards.

The PPCD-100 C-Frame press comes with a 550 x 550 mm bolster table with T-Slots and a hydraulic piston with a threaded end for attaching a variety of tools.  This press has a throat depth of 325 mm and a maximum daylight height of 400 mm.

The cylinder can operate at 2 speeds with a max approach speed of 21 mm/s, a working speed of 4.8 mm per second, and a return speed of 32 mm/s.

The PPCD-100 C-Frame Press is manufactured in the EU to the latest CE Regulations and Directives and with top-quality steel and components and the machine weighs a hefty 2500 kg.  This press has a standard 2-Year Warranty.

    Specification Sheet Download Here
    • Description
    • Additional Info

    Technical specifications

    • Force [tn]: 100
    • Motor power [kw]: 5.5
    • Throat depth [mm]: 325
    • Working speed [mm/sec]: 4.8
    • Approaching speed [mm/sec]: 21
    • Return speed [mm/sec]: 32
    • Maximum pressure [bar]: 320
    • Piston stroke [mm]: 250
    • Lower table (bolster) size [mm]: 550 x 550
    • Daylight Max. [mm]: 400
    • Bolster Table working height [mm]: 900
    • Total length [mm]: 1470
    • Total width (frontal) [mm]: 850
    • Total height [mm]: 2155
    • Weight [kg]: 2500


    • Bolster Table equipped with T-grooves
    • The cylinder is mechanized at the end to adapt tools and moulds
    • The cylinder stroke is easy to adjust with the end-stroke switches
    • Manual / semi-automatic work mode
    • Two cylinder speeds
    • Pressure switch and manometer
    • Operation by two-hands push buttons

    Optional accessories

    • Configuration of press adapted to your requirements (for example a larger table, larger vertical light or larger piston stroke)
    • Higher speeds with a different pump
    • Hydraulic ejector
    • Punching tool-set for diameters from 6 up to 100 mm with anti-deformation elastic hold-down
    • 415 mm folding tool-set (Promecam clamping system)
    • Cooling equipment for the hydraulic group by an air-oil cooling system
    • Mechanical regulation of the cylinder, only available for the PPCD-80 and PPCD-100

    Suitable for various materials

    C-Frame Presses are useful in every factory or workshop and are not only useful for mild steel but a variety of other materials also such as copper, brass, stainless steel, and carbide.  C-Frame presses are used for punching, pressing, coining, straightening, forming, bending and, drawing and are useful in every industry.  The RHTC C Frame presses come equipped with standard tools, but custom tools are also available from WorkshopPress.co.uk and we can use our in-house 3D manufacturing capabilities to assist in the design of custom press tools to suit your application.
    All of the RHTC Profi Press C-frame presses are manufactured in Europe according to the latest CE standards and are supplied directly from our warehouse with a CE certificate.  All components and materials are of the best possible quality which lends to the machines hefty weight of 1750 kg.

    CE Certificate

    This press comes with a standard 2-Year Warranty and a CE Certificate as standard.

    All Profi Presses by RHTC are customisable, integrative, and have custom tools available.
    Please contact Workshoppress today with any questions by telephone at +44 (0) 800 999 1090, or by email at info@workshoppress.co.uk.
