Vice 85 mm for Drilling and Milling
Product Code: PDV-85This Standard 85 mm Drilling and Milling Vice is Ideal for use when drilling and milling light to medium materials and for vertical and horizontal operations, as well as many other workshop metalworking functions. This vice uses a heavy-duty mechanical clamping system that is manually operated with speed and ease allowing the operator to carry out required milling and drilling functions safety and efficiently. The vice jaws feature one grooved and one flat replaceable jaw that can accommodate square, round, rectangle, hexagonal profiles as well as thin strips and discs. Both the jaws and lead screw are hardened and accurately ground ensuring accurate milling and drilling operations helping you save time and enhance profitability.
Please contact for prices
- Description
- Additional Info
This Standard 85 mm Drilling and Milling Vice is Ideal for use when drilling and milling light to medium materials and for vertical and horizontal operations, as well as many other workshop metalworking functions. This vice uses a heavy-duty mechanical clamping system that is manually operated with speed and ease allowing the operator to carry out required milling and drilling functions safety and efficiently. The vice jaws feature one grooved and one flat replaceable jaw that can accommodate square, round, rectangle, hexagonal profiles as well as thin strips and discs. Both the jaws and lead screw are hardened and accurately ground ensuring accurate milling and drilling operations helping you save time and enhance profitability.
SKU: PDV-085 Specifcations
Description: 85 mm Standard Drill Press Vice
Vice Type: Drill Press
Base Type: Fixed
Mounting Type: Bolt / Clamp / T-Slots
Framework Material: Cast Iron
Jaw Material: Tool Steel
Body Length: 174 mm
Overall Length: 234 mm
Overall Width: 142 mm
Overall Height: 58 mm
Jaw Height: 30 mm
Jaw Opening / Clamping Capacity: 70 mm
Jaw Width: 80 mm
Slot Width: 12.5 mm
Slot Length: 105 mm
Weight: 3.6 Kg
Features
Clamping range within several turns
Constant Length when clamping
Spindle thread with protected sleeve
Solid and Ridig design
Cast Iron Body
Movable jaws with side guide
Clamping Jaw mounting V-Slot
Both jaws with support surface for clamping flat workpieces
Blackend Jaws and Spindle
Variety of mounting slots
This Pillar Drill Vice is made of high-quality cast iron, it has two clamping jaws and a tool rest. It is lightweight, practical and easy to use. You canfasten the vice onto the table of the pillar drill with T-Nuts and screws or clamps. The vice holds the workpiece firmly that is to be drilled or milled allow for accurate drill holes or milling operations. A pillar drill vice is suitable for all kinds of materials and material profiles. Aluminium, mild steel, stainless steel, brass, chromolly, and many other materials can be clampped wit the standard pillar drill vice. It is also good for clamping round, square, flat, rectangle, and octagonal profiles and can also clamp special profiles with specials jaws.
