Profi Punch 16 TON • PP-16 C-Frame Press/Punching Machine
Product Code: PPP10010The Profi Punch 16 TON is an advanced hydraulic punching machine engineered for precision metal fabrication. This European-made unit features a sturdy C-frame design, allowing it to function both as a punching machine and a compact press. With a 16-ton punching force, this machine is suited for a variety of applications, including hole punching, notching, and cutting operations.
Equipped with a 2.2 kW motor, the Profi Punch 16 TON achieves a working speed of up to 9.8 mm/sec and a return speed of 20 mm/sec, ensuring efficient operation. The adjustable 70 mm stroke allows precise depth control, while the 160 mm throat depth provides flexibility for different material sizes. This hydraulic press supports manual and automatic modes, enhancing usability across various industries.
The machine is compatible with an array of interchangeable punch tools, including corner notching, pipe cutting, slotted hole punching, and sheet metal cutting. Custom tooling options are available for specialized applications.
For an industrial-grade solution combining power, precision, and versatility, the Profi Punch 16 TON is the ultimate choice for metal fabrication professionals.
Please contact for prices
- Description
- Additional Info
The Profi Punch ‘16 is a robust 16-ton hydraulic punching press designed for high-precision metalworking applications including punching, profiling, bending, and flattening. With a generous 270 mm vertical daylight and 70 mm stroke, this compact hydraulic press supports versatile operations. It is fully compatible with the standard range of Profi Punch tools and can also be configured with bespoke tooling solutions tailored to specific customer requirements and applications. Its adjustable limit switches and foot pedal control ensure precision, safety, and ease of use for professionals across manufacturing, fabrication, and repair sectors.
Technical Specifications
- Pressing Force [ton]: 16
- Max Pressure [bar]: 180
- Piston Stroke [mm]: 70
- Vertical Daylight [mm]: 255
- Shut Height [mm]: 185
- Working Speed Max [mm/s]: 9.8
- Working Speed Min [mm/s]: 2
- Return Speed [mm/s]: 20
- Motor Power [kW]: 2.2
- Hydraulic Pump Output [l/min]: 4
- Hydraulic Fluid Tank [l]: 23
- Voltage [V]: 400V, 50Hz, 3-Phase
*** (220V on request) - Length [mm]: 800
- Width [mm]: 450
- Height [mm]: 1430
- Weight [kg]: 350
Key Features
- 16-ton hydraulic press ideal for metal punching and forming
- 270 mm vertical daylight for tooling flexibility
- 70 mm adjustable stroke with limit switches
- Foot pedal operation with safety circuit integration
- Compatible with Profi Punch ’10 tooling system
Industries and Uses:
- Metal fabrication workshops
- Sheet metal processing
- Automotive component manufacturing
- Construction and structural steelworks
- General industrial pressing and punching applications
The Profi Punch 16 TON is a versatile hydraulic punching machine that doubles as a C-frame press, offering precision punching and pressing operations with a 2.2 kW motor, 70 mm stroke, and interchangeable tooling.
